Biological Filters/Waterfall Weirs

Oase Clear Water Guarantee is a manufacturer's guarantee, supported by Oase.
More information about the Clear Water Guarantee click
here

Tired of cleaning your filter pads and biological media?


Is fish growth taxing your filtration system?Interested in making your existing water feature more maintenance friendly and less time consuming with minimal disturbance to your property?

Upgrade your Watergarden for easier and superior performance.


With a simple turn of a handle, sludge and organic waste can be back-flushed quickly and easily. Back-flush nutrient-rich water on your trees and shurbs

Oase - Bio Press UVC
Bio Press UVC mechanical and biological filter with UV Light.
Easy cleaning function with integrated handle.
Ideal for small ponds and overwintering fish in your home or in the garage.

Model           Max Pond              Max Flow Rate             Inlet/Outlet Size

BP1000         250 Gallons              1050 GPH                  3/4", 1", 1.25",  1.5"

BP1600         400 Gallons              2000 GPH                  3/4", 1", 1.25",  1.5"

BP2400         600 Gallons              2100 GPH                  3/4", 1", 1.25",  1.5"

Oase - FiltoClear Pressure Filter
The FiloClear Pressure Filter is a compact all-in-one pond filtration system with a patented Easy-Clean function making it the fastest & most convenient cleaning
mechanism on the market. The built-in cleaning mechanism makes filter maintenance possible in a matter of minutes.

FiltoClear systems & built-in UV Clarifier with bypass for optimal efficiency & low power usage.



Built-in cleaning function of the FiltoClear makes regular cleaning quick and easy.
FiltoClear systems can be installed unobtrusively by burying up to 2/3 of the filter below ground.
Simply turn off the pump, rotate the cleaning switch, pull the cleaning handle a few times to loosen debris, turn the pump back on to flush the filter, then flip the switch back - that easy.


Model                Max Pond          Size: Diameter x Height            Max Flow Rate          UVC            Inlet/Outlet Size

FC3000              750 Gallons                            15″ x 20″                     2000 GPH            18 watt               1.5", 2"

FC8000            2000 Gallons                            15″ x 30″                     4000 GPH            55 watt               1.5", 2"

UV-Clarifier
The built-in UV-Clarifier makes the FiltoClear Pressure Filter your all in one filtration solution. From the moment you add the filter to your pond the UV-Clarifier starts flocculating (clumping) microscopic green algae, which then can be removed very easily by the filter.

PRESSURIZED FILTRATION
Pressurized filters allow for the use of Waterfalls or Watercourses in your backyard pond. This feature allows you to have all the necessary components for sustaining life in your pond while allowing you to use only one pond pump and filter to reach your waterfall.

EASY CLEANING MECHANISM
With a simple rotation of the cleaning switch and a few pulls on the cleaning handle will easily and effectively remove trapped debris inside the filter, without ever getting your hands dirty.

Aqua UltraViolet External Pressure Filters

These top of the line biofilters provide mechanical and biological filtration in one package. Comes with built-in turn handle back-flush assembly for easy maintenance. They can also be left in the ground over winter.
These are invaluable for a pond with heavy fish loads or provide a professional grade solution for biological filtration where our Filterfalls will not work within the space allocated.



  • Can be buried up to control head, if desired, for easy concealment

  • Simple to assemble and set up

  • Easy backflush

  • Includes Ultimate non-clogging bio media with 750 SSA

  • Minimal back pressure – high flow rate media creates very little back pressure

Model                Max Pond          Size: Diameter x Height            Max Flow Rate @10′ of head                 Inlet/Outlet Size

AA10             1000 Gallons                            14″ x 23.25″                                1000 GPH                                          1 1/2″

AA20             2000 Gallons                         16.5″ x 33″                                     2000 GPH                                                 2″

AA40             4000 Gallons                            21″ x 39″                                     4000 GPH                                                 2″

AA60             6000 Gallons                         22.5″ x 42″                                     6000 GPH                                                 2″

AA100        10,000 Gallons                      23.75″ x 44″                                     6000 GPH                                                 2″

AA200        20,000 Gallons                        30.5″ x 48″                                     7500 GPH                                                 2″

AA300        30,000 Gallons                        36.5″ x 49″                                     7500 GPH                                                 2″

AA300s       30,000 Gallons                       36.5″ x 49″                                  20,400 GPH                                                 3″

AA600s       60,000 Gallons                          39″ x 42″                                  20,400 GPH                                                 3″

AA600 sa (w/ autoback flush)
                    60,000 Gallons                          39″ x 42″                                   20,400 GPH                                                 3″

True Rock’ artificial boulders

True Rock’ artificial boulders are ideal for concealing pressure filter control heads, air pumps,
water pumps, pond filters, UV filters, lighting transformers and other equipment.

    • Commercial-grade heavy-duty construction stands up to the elements

    • Colour and texture is part of material, not painted on

    • Lightweight, easy to move and very durable

    • Will not fade or crack and are made of recycled material

  • Medium

    Dimensions
    27″L X 21″W X 14″H

    Colour: Greystone / Sandstone


  • Large

    Dimensions:
    33″L X 24″W X 20″H

    Colour: Greystone / Sandstone

UV STERILIZERS
All UV’s aren’t created equal! The bottom line for UV users is Performance. Aqua Ultraviolet, with 27  years of UV manufacturing excellence, is unsurpassed at delivering high UV output, intensity and high flow rates while delivering superior quality, design, construction, features, lamp life, warranty and customer service.

UV STERILIZER
  8 Watt with wiper 3/4”
25 Watt with wiper 2”
57 Watt with wiper 2”

Replacement UV lamps are available

Description                Fresh Water                    Fresh Water
                                Sterilizer (gallons)          Clarifier (gallons)

Classic   8 Watt           5-200                              up to 1500

Classic 15 Watt        200-500                             up to 2000

Classic 25 Watt      500-1200                             up to 4000

Pro Fast Falls
Complimentary to the structural integrity of our Filterfalls, the Pro Fast Falls is a great solution for waterfall features in challenging locations.

Pond liner can be attached to the back of the Pro Fast Falls or simply
inserted into a lined cavity.

It should be noted that this is not a biological filter.

Three sizes available
:
Mini

Waterfall Width: 16″
Dimensions:  16.5″ x 9.5″D x 7.25″H
Max Pump Flow: 3000 GPH

Small
Waterfall Width: 19″
Dimensions:  20.5″ x 17″D x 10.25″H
Max Pump Flow: 4000 GPH

Medium
Waterfall Width: 26″
Dimensions:  27.5″ x 17″D x 10.25″H
Max Pump Flow: 6000 GPH

Large
Waterfall Width: 38″
Dimensions:  39.5″ x 17″D x 10.25″H
Max Pump Flow: 9000 GPH

Waterfall installed with three Fast Falls waterfall weirs.
The low profile design makes it easy to hide with vegetation and rocks. All you should really see it the sight of water with a beautiful cascading waterfall.

PRO SERIES BIOLOGICAL FILTERS

Pro Series Biological Waterfall Filters are manufactured under rotational moulding process. This method of manufacture offers superior design advantages over other moulding processes, such as injection moulding. The process has a number of design strengths, such as consistent wall thickness and strong outside corners that are virtually stress-free. These attributes are particularly vital for the harsh frost conditions an Alberta winter can through at us.

Pro Series Waterfall Filters and not only help keep your pond clean and healthy, it is also the ideal start to your stream or waterfall. An inlet hole is located at on either side of the Biological Filter, for convenient PVC pipe connection from the skimmer.

Pro Series Biological Waterfall Filters are buried in the ground so that they are hidden from view with earth excavated for the pond. A dense filter mat ensures that clean water flows through the high-grade bio media located on top for beneficial bacteria germination and growth. In addition to this, our Pro Series Biological Filters comes complete with a backflush system which allows you to quickly and efficiently cleanse the biofilter during the season for optimum performance.

You get what you pay for. And what you are paying for is the colonization of billions of more aerobic bacteria in your up-to-date bio media working away hard at eating up all those algae-promoting nutrients. Low nutrient levels result in clean, clear, healthy water that green algae just simply have a very difficult time surviving in. So we are not killing algae, we are just starving it out – naturally.

Pro Series FilterFalls Features:

1. Heavy-duty removable top grate supports rock camouflage

2. Support bars add stability and reinforce top grate

3. Media bag. (Professional grade & back-flushable friendly Bio-Matrix media sold separately to provide max surface area for development of beneficial bacteria)

4. Dual Bio-Tech filter mats for mechanical  filtration

5. Sturdy bottom grate supports filter media

6. Rolled upper rim provides clean lines and incredible strength

7. 2” or 3” heavy-duty FIPT bulkhead for high flow rates

8. Bottom chamber accepts bulkheads on all sides while bottom cones reduce surface area for back-flushing

9. One-piece liner flange allows easy, leak-free attachment of FilterFalls to pond liner

10. Solid lip and moulded-in inserts ensure a watertight liner attachment every time

11. Lifetime Warranty

Model: BF1600

Waterfall Width: 16” spillway



Dimensions: 21½”W x 19½”D x 17¾”H


Pump Flow Range: 1,000 – 3,000 gph


Bulkhead: 1½”

Model: BF1900

Waterfall Width: 19” spillway

Dimensions: 28”W x 25”D x 21½”H

Pump Flow Range: 2,500 – 4,000 gph

Max Pond Size: 8’x10′

Bulkhead: 2”

Match to Skimmer: PS4600

Model: BF2600

Waterfall Width: 26” spillway

Dimensions: 34½”W x 25”D x 23”H

Pump Flow Range: 4,000 – 6,000 gph

Max Pond Size: 10’x15′

Bulkhead: 2”

Match to Skimmer: PS7000

Model: BF3800

Waterfall Width: 38” spillway

Dimensions: 46½”W x 30”D x 23”H

Pump Flow Range: 6,000 – 8,000 gph

Max Pond Size: 15’x20′

Bulkhead: 3”

Match to Skimmer: PS15000

Spillway Basins & Kits

Atlantic 12" Basin Kit

For use with all 12" wide spillways

Dimensions: 20" x 20" x 16"

Kit Includes:

  • 20" wide basin

  • Tidal Wave 1200 GPH pump

  • 10' x 1.5" flex PVC

  • Anti-splash mat

  • Autofill valve kit

  • Complete instructions & all necessary glue & fittings

Atlantic 24" Basin Kit

For use with all 12" wide spillways

Dimensions: 40" x 22" x 16"

Kit Includes:

  • 44" wide basin

  • Tidal Wave 2400 GPH pump

  • 10' x 1.5" flex PVC

  • Anti-splash mat

  • Autofill valve kit

  • Complete instructions & all necessary glue & fittings

Atlantic 36" Basin Kit

For use with all 36" wide spillways

Dimensions: 56" x 24" x 16"

Kit Includes:

  • 56" wide basin

  • Tidal Wave 3600 GPH pump

  • 10' x 1.5" flex PVC

  • Anti-splash mat

  • Autofill valve kit

  • Complete instructions & all necessary glue & fittings

Recommended Products

  • Description: 12" Stainless Steel Spillway

  • Flow Rate: 1,200 gph

  • Projection: 9-10" at 18"H & 1,200 gph

  • Inlet: 1½" FIPT

  • Dimensions: 12"W x 8½"D x 4"H

  • Description: 24" Stainless Steel Spillway

  • Flow Rate: 2,400 gph

  • Projection: 9-10" at 18"H & 2,400 gph

  • Inlet: 1½" FIPT

  • Dimensions: 24"W x 8½"D x 4"H

  • Model: SS36

  • Description: 36" Stainless Steel Spillway

  • Flow Rate: 3,600 gph

  • Projection: 9-10" at 18"H & 3,600 gph

  • Inlet: 1½" FIPT

  • Dimensions: 36"W x 8½"D x 4"H
